Digital height and marking gauges RDCT in box Double column, with fine and quick adjustment 1000/0,01mm IP54
Illustration similar ©ULTRA Germany
€1,587.00*
Custom price after Login
Article number:
1808103
Delivery time
approx. 7 weeks
Shipping method:
Truck freight
Weight:
13kg
EAN / GTIN:
4066918069221
Manufacturer number:
40002
Customs code:
90172039
Do you need more information?
| Login/Register | |
| +49 (0) 6021 42 999 00 | |
| Contact |
Digital height and marking gauges RDCT in box Double column, with fine and quick adjustment
- Works standard
- Protection class IP54, Sylvac System
- Cast iron base with round columns made of hardened stainless steel
- Fast up and down with central push button
- Fine adjustment with knurled nut at a central threaded spindle
- Large LCD display
- Steel scriber, hardened
Delivered in a case
Functions:
- On/Off
- mm/inch commutation
- Zero setting at any position
- Preset function ±
- Hold function
- Data output Opto
| Digital height and marking gauges RDCT in box Double column, with fine and quick adjustment | |
|---|---|
| Size: | 1000/0,01mm IP54 |
| Article number: | 1808103 |
| Brand: | DEMM |
| Manufacturer number: | 40002 |
| Measuring range: | 1000mm / 40 inch |
| Reading: | 0,01mm / .0005 inch |
| Protection class: | IP54 |
| Columns: | Ø 20mm |
| Base: | 117x204mm |
| Material base: | Cast iron |
| Perpendicularity: | 0,08mm |
| Accuracy: | 0,04mm |
| Data output: | Opto |
| Weight: | 13kg |
