Digital dial indicators S_Dial Work NANO with LED tolerance signal lights 25/0,0001mm Ø60mm
€1,077.00*
Custom price after Login
Do you need more information?
| Login/Register | |
| +49 (0) 6021 42 999 00 | |
| Contact |
Digital dial indicators S_Dial Work NANO with LED tolerance signal lights
- Works standard
- Protection class IP54
- Inductive measuring system
- Large LCD display, turnable up to 270°
- Individually programmable key with required functions
- Repeatability 0.0005mm
- Aluminium housing Ø 60mm
- Clamping shaft Ø 8mm h6
- Interchangeable measuring insert M2.5
Delivered in a cardboard box incl. works calibration certificate
Functions:
- On/Off
- Auto-Off
- mm/inch commutation
- Zero setting at any position (2 reference points)
- Hold function
- ± Preset function
- MIN. / MAX. memory
- Tolerance signal lights LED red/green/yellow
- Reversible measuring direction
- ABS function
- Key lock
- Data output Proximity
| Digital dial indicators S_Dial Work NANO with LED tolerance signal lights | |
|---|---|
| Size: | 25/0,0001mm Ø60mm |
| Article number: | 1300102 |
| Brand: | SYLVAC |
| Manufacturer number: | 805.5506 |
| Reading: | 0,0001mm / .00005 in |
| Bluetooth: | Without |
| Measuring range: | 25mm / 1 inch |
| Error max.: | 0,0022mm |
| Measuring force: | 0,65 - 1,15N |
| Cal. certificate: | Without |
| Weight: | 0.23kg |
€151.00*
All variations:
€994.00*
€1,077.00*
