PROMOTION
incl. packing
Granite measuring plates DIN 876/0 incl. base tool cabinet, calibration certificate and packing 1000x630x100mm
Dimension:
1000x630x100mm
|
Grade:
0
|
Type:
With tool cabinet
DIN 876
made from finest natural granite with a particularly homogeneous structure
Measuring surface diamond lapped, corrosion-resistant and acid-resistant
Finely grounded outer surface
Hardness 6–7 on Moh’s scale
Delivered including calibration certificate and packing
Accuracy:
The final machining takes place in the climate room at a constant temperature and humidity.
For final inspection, measuring devices are used, which are traceable to national and international calibration laboratories.
1503 2..: Grade 00 very high precision for control room, with base tool cabinet
1503 1..: Grade 0 high precision for workshop, with base tool cabinet
1504 2..: Grade 00 very high precision for control room, with stand
1504 1..: Grade 0 high precision for workshop, with stand
Base tool cabinet:
Stable square pipe with drawer module
3 drawers with telescope inserts
Color drawer module RAL 5015
Including levelling screw and tilt protection
Height adjustable base
Construction dimensions for approx. 900 - 950mm working height
Stand
Stable square pipe
Incl. levelling screw and tilt protection
Construction dimensions for approx. 900 - 950mm working height
Color stand RAL 7035
! Plate thickness for T-slots min. 100mm.
! Other sizes, plate thicknesses, higher accuracy grades and special versions according to drawing on request.
€2,701.00*
PROMOTION
Articulated measuring stands Classic Line 2200-20 F + M magnetic, mechanical centre lock and micro fine adjustment 200/310mm
Base:
switch magnet
|
Base dimension:
60x50x55mm
|
op. range/height:
200/310mm
Freely adjustable arm
Chrome-plated linkage
Magnetic V base
Switchable magnet
Dial mounting hole Ø 8mm
Delivered in individual packages, without dial gauge
Applications:
The small Classic model for measurement probes and dial gauges can be used in any type of mechanical system. Pre-tensioning cannot be set.
€257.00*
PROMOTION
Vernier calipers ULTRA active inox matt in box Without points, with fine adjustment 1500x200-1/20mm
Jaw length:
200mm
|
Measuring range:
1500mm / 60 inch
|
Points:
Without
|
Reading:
1/20mm / 1/128 inch
DIN 862 up to jaw length 200mm, from 250mm according to works standard
Locking screw
Hardened stainless steel
Satin chromed vernier and scale
Delivered in a case
1895 1..: Without points
1896 1..: With points
! Vernier 1/50mm on request.
€1,159.00*
PROMOTION
Limit Plug Gauges steel, aluminium handle green/red length 20mm / chamfered edge / +1µ / -1µ Ø 0,500-1,999/0,001mm
Material:
Hardened steel
|
Nominal size:
Ø 0,500-1,999mm
|
Step:
0,001mm
Works standard
Double life time due to reversible pins
Usable measuring length approx. 20mm
≥ Ø 2.0mm with chamfer
Manufacturing tolerance GO side +0.001mm / NO-GO side -0.001mm
Gauge handles marked with gauge sizes according to your requirement
The additional marking of an ID-number will be made against extra charge
Delivered in individual packages
1081 4.. : Material hardened tool steel 58–62 HRC
1089 1.. : Material tungsten carbide 90-93 HRA
1090 3.. : Material ceramic 89-90 HRA
! Other pin lengths as well as single ended plug gauges on request.
! Order notice - Please enter exact nominal size, examples:
GO side Ø 8.21mm and NO-GO side Ø 8.23mm
GO side Ø 12.542mm and NO-GO side Ø 12.548mm
€81.00*
PROMOTION
Precision meas. tables, ceramic surface Adjustable arm 180x215/200mm DIN 876/000
Arm:
Adjustable
|
Height:
200mm
|
Measuring surface:
180x215mm
DIN 876/000
Extremely hard, anti-corrosive and absolutely wearresistant measuring surface with dust grooves
Special cast iron base
Dial mounting hole Ø 8mm
Helical thread ground ex works, stainless hard chrome-plated steel, h7
Height adjustment by helical thread with adjusting ring
Delivered in individual packages
! Larger measuring heights and special stands on request.
€1,757.00*
PROMOTION
Measuring cylinders 90° hardened special steel Ø60x160mm
Diameter:
60mm
|
Height:
160mm
|
Material:
Special steel
Works standard
Hardened special steel
Machined base and jacket surface
with handle
Delivered in individual packages
1631 1..: Hardened special steel
1633 1..: Storage box
! Other sizes and higher accuracy grades on request.
€366.00*
PROMOTION
incl. packing
Granite measuring plates DIN 876/00 incl. calibration certificate and packing 800x600x80mm
Dimension:
800x600x80mm
|
Grade:
00
DIN 876
Made from finest natural granite with a particularly homogeneous structure
Measuring surface diamond lapped, corrosion-resistant and acid-resistant
Finely grounded outer surface
Hardness 6–7 on Moh’s scale
Bottom surface with statically correct mounted steel ball inserts as bearing points
Accuracy:
The final machining takes place in the climate room at a constant temperature and humidity.
For final inspection, measuring devices are used, which are traceable to national and international calibration laboratories.
1500 1..: Grade 000 highest precision for laboratory
1501 1..: Grade 00 very high precision for control room
1502 1..: Grade 0 high precision for production
1505 1..: Grade 1 high precision for workshop and production
Delivered with steel ball inserts and calibration certificate
! Plate thickness for T-slots, min. 100mm.
! Other sizes, plate thicknesses, higher accuracy grades and special versions according to drawing on request.
€915.00*
PROMOTION
Articulated measuring stands Strato Line S-20 F + M magnetic, mechanical centre lock and micro fine adjustment 200/310mm
Base:
switch magnet
|
Base dimension:
60x50x55mm
|
op. range/height:
200/310mm
Freely adjustable arm
Aluminium linkage
Magnetic V base
Switchable magnet
Dial mounting hole Ø 8mm
Delivered in individual packages, without dial gauge
Applications:
The mid-range Strato model for measurement probes and dial gauges can be used in any type of mechanical system. Pre-tensioning cannot be set.
€281.00*
PROMOTION
Setting ring gauges DIN 2250-C tungsten carbide Special sizes Ø 5,000-14,999/0,001mm
Nominal size:
Ø 5,000-14,999mm
|
Step:
0,001mm
DIN 2250-C
Gauge body in steel, measuring face insert in tungsten carbide
Manufacturing tolerance JS4
All nominal diameters in 0,001mm step
Delivered in individual packages
! Larger nominal sizes as well as setting ring gauges for pneumatic measuring acc. DIN 2250-B on request.
! Order notice - Please enter exact nominal diameter, e.g. Ø 10,282mm or Ø 37,58mm
€199.00*
PROMOTION
Pin gauge sets Tol.±0.001mm in wooden box Tungsten carbide DIN 2269 Ø 0,50-1,00/50/0,01mm
Nominal size:
Ø 0,50-1,00mm
|
Step:
0,01mm
|
Tolerance:
±0,001mm
DIN 2269
Hardness 90-93 HRA
Larger than Ø 1.5mm with chamfer
Nominal size marked from Ø 2.0mm on pin gauges
Including additional plastic sleeves per pin with marking of nominal size
Delivered in wooden box
! Other set compositions as well as pin gauge sets with handles on request.
€885.00*
ULTRA PRÄZISION MESSZEUGE GMBH - Your competent partner for dimensional metrology!
Welcome to the pages of ULTRA PRÄZISION MESSZEUGE GMBH - your specialist trade partner for measuring tools and gauges. We offer you a unique range of gauges and dimensional standards, measuring tools, testing equipment, measuring plates, alignment tools, and components for clamping technology. ULTRA measuring tools and gauges have stood for the highest precision and excellent quality for over 135 years.
The ULTRA Shop is the clever solution for your daily procurement!
In the ULTRA Shop, we offer you an extensive range of products in the field of metrology 365 days a year, which also meets the highest quality standards. In addition to our ULTRA brand products, we stock a large inventory of high-quality products from well-known manufacturers.
Benefit from our excellent prices and delivery capability for: BOWERS XT, XTD, XTH 3-point micrometers and measuring instruments, DEMM / Sylvac carbon calipers and testing equipment, FISSO measuring stands, KÄFER dial indicators, KRÖPLIN dial caliper gauges, SCHWENK precision bore gauges, LEITECH thread plug gauges, and PESOLA fine spring balances.
Use our strong brands for your business success!
Our specified online
shop
offers you over 10.000 products in the following categories:
We are not only available online, but also in real life!
Our headquarters are located in Glattbach near Aschaffenburg / Germany. If you are looking for an expert contact person for solutions in the field of dimensional metrology, we are here for you and offer you the optimal solution for every application. With us, you can discuss all questions about metrology with experienced and knowledgeable experts - in person, by phone, or by email. We provide honest and competent advice and always have a genuine interest in your requirements.
It does not work without the right service!
If necessary, you can conveniently configure our measuring tools and gauges in the shop with a factory calibration certificate, DAkkS calibration certificate and individual engraving (e.g. internal ID numbers).
If you cannot find the suitable products in our shop or have a specific need for gauges, precision parts, or test fixtures according to your drawings, do not hesitate to send us your inquiries via our contact form
Our sales team will gladly check our manufacturing capabilities and provide you with an attractive offer.
